WILDEN Pump 00-10185 is a classic 1/4 inch Pro-Flo SHIFT bolt-type air-operated double diaphragm pump, with model specification PS25/PPPPP/ZGS/GS/PBN, specially designed for precision and complex medi…
| Flow Rate | Up to 22 L/min (5.7 gpm) |
|---|---|
| Head | Up to 84 m (8.3 bar / 120 psi air pressure) |
| Inlet / Outlet Diameter | 1/4" (6 mm) NPT |
| Material | Polypropylene |
WILDEN Pump 00-10185 is a classic 1/4 inch Pro-Flo SHIFT bolt-type air-operated double diaphragm pump, with model specification PS25/PPPPP/ZGS/GS/PBN, specially designed for precision and complex medium conveying working conditions.
This model adopts high-quality PP polypropylene plastic pump body and exclusive Bunalast™ professional diaphragm, with excellent anti-corrosion and wear resistance. Internal matching accessories adopt durable Carbon Filled Acetal, ensuring stable operation of precision components. It supports a maximum working pressure of 120PSI and a peak flow rate of 5.7GPM, with a maximum passing solid particle diameter of 0.06 inches, which can adapt to slurry, abrasive media and high-viscosity media up to 125000cP.
Equipped with EZ-Install full-stroke diaphragm design, the pump has enhanced durability and stability in long-term conveying of abrasive and viscous media. It adopts NPT thread right-side water inlet and outlet structure, with simple installation and convenient pipeline matching.
WILDEN 00-10185 pump features compact structure, precise flow control and strong medium adaptability, which is widely used in small industrial fluid systems, precision chemical conveying and low-flow slurry transfer scenarios, and is a high-precision miniature AODD pump with stable performance.
Need More Information?
If you need to know more details about WILDEN air-operated double diaphragm pumps or have any questions about product selection, installation, operation and maintenance, please contact the professional engineering and technical personnel of Haquan Pump & Valve. We will serve you wholeheartedly, and your satisfaction is our greatest pursuit.
