Model: WILDEN P1 (Pro-Flo, clamped)
Genuine WILDEN P1, the 1/2″ clamped Pro-Flo aluminum pump: 20 builds and six diaphragm materials. How rubber and PTFE builds differ in flow and lift.
| Flow Rate | Up to 15.4 gpm / 58 L/min (3.5 m³/h) |
|---|---|
| Head | Max air pressure 125 psi / 8.6 bar |
| Power | Compressed air, max 8.6 bar (125 psi) |
| Inlet / Outlet Diameter | 1/2" inlet / 1/2" outlet, NPT, center ports |
| Material | Aluminum wetted path, polypropylene air side; Santoprene, PTFE, Buna-N, EPDM, Hytrel or FKM diaphragms |
With the P1, the question we hear most is not about size but about the diaphragm. PSG lists 20 aluminum P1 builds with six different diaphragm materials: Santoprene, PTFE, Buna-N, EPDM, Hytrel and FKM. The choice changes more than chemical resistance.
| Santoprene build (01-2677) | PTFE build (01-2652) | |
| Max flow | 15.4 gpm (58 L/min) | 14.4 gpm (55 L/min) |
| Dry suction lift | 17 ft (5.2 m) | 16 ft (4.9 m) |
| Diaphragm stroke | Full stroke | Reduced stroke |
| Min temperature | 32 °F (0 °C) | 40 °F (4 °C) |
| Max temperature | 175 °F (79 °C) | 175 °F (79 °C) |
| Shipping weight | 13 lb (5.9 kg) | 11.3 lb (5.1 kg) |
PTFE resists almost every chemical, but it is stiffer, so Wilden runs it with a reduced stroke. That costs a little flow and suction lift. A rubber diaphragm gives full stroke and slightly better performance, as long as it is compatible with the liquid.
This is only a starting point. Send us the liquid, its concentration and temperature, and we will check the compatibility before you order. All P1 builds are 1/2 inch NPT with center ports and handle solids up to 0.06 inch (1.5 mm).
| Part No. | Build code | Elastomer | Connection |
| 01-2652 | P1/AAPPP/TNU/TF/ATF | PTFE | Threaded |
| 01-2677 | P1/AAPPP/WFS/WF/SWF | Santoprene | Threaded |
| 01-2653 | P1/AAPPP/BNS/BN/ABN | Buna-N | Threaded |
| 01-10973 | P1/AAPPP/FSS/TF/AFS | Hytrel | Threaded |
| 01-11018 | P1/AAPPP/EPS/TF/ATF | EPDM | Threaded |
| 01-2689 | P1/AAPPP/VTS/VT/ATF | FKM | Threaded |
Browse all 20 aluminum P1 builds: https://www.haquanpump.com/wilden-aodd-pumps/part-numbers?q=P1
