The Full QBY FamilyThe QBY series covers eight standard sizes from 10 mm to 100 mm. Flow ranges from 0.8 m³/h to 30 m³/h. Head goes up to 60 meters. There’s a model for almost every job. Complete Mode…
| Flow Rate | 0-30m³/h |
|---|---|
| Head | 0 – 50 / 70m |
| Inlet / Outlet Diameter | 10 – 100mm |
| Material | PP Engineering Plastic, Aluminum Alloy, Cast Iron, Stainless Steel |
Not sure this pump fits your duty? Try the pump selector
The Full QBY Family
The QBY series covers eight standard sizes from 10 mm to 100 mm. Flow ranges from 0.8 m³/h to 30 m³/h. Head goes up to 60 meters. There’s a model for almost every job.
Complete Model Overview
| Model | Port Size | Max Flow | Max Head | Solids | Material Options |
|---|---|---|---|---|---|
| QBY-10 | 10 mm | 0.8 m³/h | 60 m | 1 mm | All |
| QBY-15 | 15 mm | 1 m³/h | 60 m | 1 mm | All |
| QBY-25 | 25 mm | 2.4 m³/h | 60 m | 2.5 mm | All |
| QBY-40 | 40 mm | 8 m³/h | 60 m | 4.5 mm | All |
| QBY-50 | 50 mm | 12 m³/h | 60 m | 8 mm | All |
| QBY-65 | 65 mm | 16 m³/h | 60 m | 8 mm | All |
| QBY-80 | 80 mm | 24 m³/h | 60 m | 10 mm | All |
| QBY-100 | 100 mm | 30 m³/h | 60 m | 10 mm | All |
How to Select
1.
Determine required flow and head
2.
Identify fluid type and chemical compatibility
3.
Choose body material accordingly
4.
Select diaphragm material for fluid
5.
Confirm air supply capacity
Final Advice
When in doubt, go one size larger. Running a pump at 80% capacity gives longer life than running at 100%.
Applications Summary:
pump selection, fluid transfer, industrial pumping, chemical handling, wastewater, mining, food processing, general industry
