Many purchasers confuse YW liquid-submerged sewage pump and fully submersible sewage pump (QW/WQ series), there are essential structural and application differences:（1）Structural LayoutYW pump: Vertic…
| Flow Rate | 2 ~ 2000m³/h |
|---|---|
| Head | 3 ~ 60m |
| Power | 0.75 ~ 250kW |
| Inlet / Outlet Diameter | 25-400mm |
| Material | Cast Iron,SS304,SS316 |
Not sure this pump fits your duty? Try the pump selector
Many purchasers confuse YW liquid-submerged sewage pump and fully submersible sewage pump (QW/WQ series), there are essential structural and application differences:
（1）Structural Layout
YW pump: Vertical liquid-submerged type, pump body under liquid, motor installed above liquid surface, no motor soaking risk.
Fully submersible pump: Whole pump including motor completely immersed in sewage during operation.
（2）Maintenance Convenience
YW pump: Motor above water, easy daily inspection, motor fault maintenance without draining sewage pool.
Submersible pump: Need to lift entire pump out of water for any motor maintenance, high operation cost.
（3）Construction Cost
YW pump does not need sealed waterproof pump pit, simple pool civil engineering; submersible pump requires waterproof pool cover and lifting device.
（4）Application Scenario
YW pump: Long-term continuous operation factory sewage station, municipal wastewater pool, medium with high solid particle content.
Submersible pump: Temporary short-time drainage, small domestic sewage, shallow liquid level environment.
（5）Service Life
YW pump motor avoids long-term liquid soaking, lower insulation aging speed, longer overall service cycle under heavy load sewage transportation.
If the project requires stable long-term unattended operation with high fiber/solid sewage, YW Type Liquid-Submerged Sewage Pump is more suitable.
