The WILDEN P15 AODD pump is the largest model in the P series with a 4-inch port size. It delivers the maximum flow rate of 1040 L/min and handles solids up to 19 mm, making it ideal for high-volume f…
| Flow Rate | 1040 L/min (62.4 m³/h / 275 GPM)m³/h |
|---|---|
| Head | 0-86m |
| Power | —kW |
| Inlet / Outlet Diameter | 6-100mm |
| Material | Aluminum Alloy, Cast Iron, SS316 Stainless Steel, Hastelloy, PP, PVDF, Carbon Filled Acetal |
The WILDEN P15 AODD pump is the largest model in the P series with a 4-inch port size. It delivers the maximum flow rate of 1040 L/min and handles solids up to 19 mm, making it ideal for high-volume fluid transfer in heavy industrial applications.
Key Features
•
Largest P series model – 4″ ports
•
Maximum flow rate – 1040 L/min
•
Passes large solids up to 19 mm
•
Multiple material options for corrosive service
•
Self-priming and dry-run capable
•
Proven reliability in 50+ years of field service
Technical Specifications
| Parameter | Value |
|---|---|
| Port Size | 4″ (DN100) |
| Max Flow Rate | 1040 L/min (275 GPM) |
| Max Working Pressure | 8.6 Bar (125 psi) |
| Max Head | Approx. 86 meters |
| Self-Priming Height | 3 – 7 meters |
| Max Solid Particle | 19 mm |
FAQ
Q: What is the weight of the P15 pump?
A: Weight varies by material; consult specification sheet for exact values.
Q: Can the P15 be used for viscous fluids?
A: Yes, it handles viscosities up to 125,000 cP.
Q: What certifications does the P15 carry?
A: CE, UKCA, and ISO9000/EN29000 certified.
Need More Information?
If you need more details about WILDEN air-operated double diaphragm pumps or have questions about product selection, installation, operation, and maintenance, please contact our professional engineering team at Haquan Pump Valve. We will serve you wholeheartedly. Your satisfaction is our greatest pursuit.
