Wilden T15 Shaft 15-3800-09-07 for Turbo-Flo Pumps

Nobody looks at the shaft until the seals start failing for no obvious reason.

The 15-3800-09-07 is the shaft on the Wilden T15, position 15 in the parts list. It joins the two diaphragms so they move together, and it runs through the center block on a pair of seals. Every stroke drags its surface across those seals, so a scratch, a pit or a patch of corrosion on it wears down new seals faster than they should go.

If you keep replacing seals, check the shaft. Light marks can sometimes be smoothed out; deep scoring can’t. And when the shaft does get changed, change the seals at the same time, otherwise a worn part just wears out the new one.

This is an original Wilden part, compatible with the matching model of genuine Wilden pump. Check the part number and position against your own parts list before ordering, and the material too if your fluid is aggressive.
