High Head Chopper Pump – WQK20-60QG Pushes 60 m, 7.5 kW

Sixty meters of head is no joke for a chopper pump. Usually, cutting pumps trade pressure for solids handling. But the WQK20-60QG manages both: 20 m³/h at 60 m head, driven by a 7.5 kW motor at 2900 rpm.
When You Need This Kind of Pressure
Think high-rise basements, long-force mains up a hill, or discharge from a deep valley pit to a ridge-top treatment plant. Standard 15–30 m head pumps stall here. This one keeps pushing, with the cutting system ensuring rags don’t accumulate in the high-pressure discharge line.

Performance Snapshot

Parameter	Value
Model	WQK20-60QG
Flow	20 m³/h
Head	60 m
Power	7.5 kW
Outlet	80 mm
Speed	2900 rpm
Voltage	380 V

A Few Hard-Won Tips

• Cable sizing: At 7.5 kW, don’t undersize your supply leads. Voltage drop at the pump terminal kills torque and cutting effectiveness.
• Mechanical seal care: High head means higher internal pressure. Inspect the double mechanical seal (graphite–SiC) annually; any leakage shortens motor life fast.
• Rotation check: Brief test run (<30 sec), swap any two phases if reversed. Never guess direction on a cutting pump — reverse rotation can affect cutter engagement.

Applications Summary:​

high-rise basement drainage, deep pit dewatering, long-distance sewage transfer, hillside discharge, pressurized sewer lines

Thanks for visiting HAQUANPUMP. If your project demands a high-head chopper pump​ like the WQK20-60QG, our engineers can review your head calculations and site layout. Contact our staff — we’ll make sure you get the right pump, not just a big number on paper.
